Dispenser Range Maxx
Equipped with a unique, reliable and sturdy dispensing mechanism that is quick and accurate. It dispenses in only one single movement an exact even quantity between 12 and 24 balls in less than 3 seconds and has integrated light-duty washing installation.
The flat lid has hydraulic springs for manual filling either at the front or the backside.
Large storage capacity compared to compact dimensions (based on model):
- 31302: 9.000 balls
- 31303: 12.000 balls
- 31304: 16.000 balls
| 31302 | 31303 | 31304 | |
| Capacity (balls) | 9.000 | 12.000 | 16.000 |
| Size (w x d x h) | 92 x 125 x 135 cm | 92 x 125 x 155 cm | 90,5 x 176,5 x 155 cm |
| Weight (empty) | approx 240 kg | approx 260 kg | approx 290 kg |
| Weight (full) | approx 700 kg | approx 850 kg | approx 1.090 kg |
General information about all three models:
- Solid steel exterior, galvanized and powder coated
- Stainless steel lock cams prevent burglary
- The level of balls is indicated by holes on every side
- Large front door enables integration of many different payment systems (order separately)
(counter and adjustable set feet included)
Technical details:
- Dispensing cycle: 2-3 seconds. Dispensing quantities per cycle: 1 row: 6,7,8,9,10, 11 or 12 balls 2 rows (standard): 12,14,16,18,20,22 or 24 balls
- Adjustable quantity of 1-4 cycles per payment
- Power: 230 VAC. Power consumption: 5-200 W
- Water inlet: 1/2" (garden hose dimension). Water drain: 40 mm
